This is the diagram of a traditional old time tube receiver. The receiver is superhet and uses 455 kHz IFs. The circuit is designed to be powered from the 110/117 AC power line. The heaters are wired in series.
MW OC Receiver Using Tubes (T032E)
- Details
- Written by: Newton C. Braga
