6N7 Tone Control (T1072E)
- Details
- Written by: Newton C. Braga
This circuit is a typical setup for a tone control using a 6SN7 dual triode tube. It serves as a suggestion to be implemented in an amplifier. The circuit is from a 1946 documentation.
