We found this signal generator circuit in a Radio Craft from 1946. The circuit uses 3 tubes, plus the power supply with the indicated voltages. The coil has 130 turns of wire 30 AWG in a 1.5 inch form to generate signals in the midwave and IF range. The tap is on the 30th turn.
