This double tube receiver circuit with headphone or loudspeaker listening was found in a documentation from 1945. The circuit has double tuning and is powered with the voltages indicated in the diagram itself.
Receiver with the 1D8 (T924E)
- Details
- Written by: Newton C. Braga
