Hartley oscillator (MA121E)

Details
Written by: Newton C. Braga

The frequency of a Hartley Oscillator is given by the LC ressonant circuit as shown in figure bellow.














Formula 1

Frequency:










Where:

F is the frequency in hertz (Hz)

L is the inductance in henry (H)

C is the capacitance in farads (F)

π is 3.14
