We found this circuit in GE's 1977 semiconductor manual. The optical isolator uses an opto-SCR, and the lamp must be 25 W maximum. Only incandescent lamps should be used.
| Clique na imagem para ampliar |
10 V lamp Logical Indicator (CB14712E)
- Details
- Written by: Newton C. Braga
