This circuit can be used with crystals from 100 kHz to 30 MHz and the resonant circuit must be adjusted to the chosen frequency. The circuit can be powered by voltages from 6 to 15 V. The coil depends on the operating frequency.
Hartley Crystal Oscillator (CB19354E)
- Details
- Written by: Newton C. Braga
