Storm Alarm (CB24633E)

Details
Written by: Newton C. Braga



This simple circuit, connected to the speaker output of an off-station AM radio, detects the crackling sounds caused by lightning strikes. The circuit was suggested by an article in the March 1980 issue of Radio Electronics magazine.




| Clique na imagem para ampliar |
