Nixie Counter (CB6620E)

Details: Written by: Newton C. Braga

Found in a 1967 General Electric documentation, this meter uses Nixie tubes, popular at a time when LED and liquid crystal displays did not yet exist.

| Clique na imagem para ampliar |
