Obtained from a 1996 documentation, this circuit uses common components and has a voltage gain of 200 times. The circuit also has an automatic gain control. The power supply need not be symmetrical.
Audio Preamplifier (CB6479E)
- Details
- Written by: Newton C. Braga
