LED Narrow Pulse Generator (CB14685E)

Details
Written by: Newton C. Braga



The presented circuit generates short pulses using a relaxation circuit with two complementary transistors that can be BC548 and BC558. The frequency is given by R1 and C1. The circuit is from a Texas Instruments opto-electronics manual.
