This circuit for old flashes with xenon lamps was found in a Radio Electronics magazine from June 1966. The sensor is a photoelectric cell from the time. Power is supplied by a 9 V battery.
| Clique na imagem para ampliar |
Slave flash (CB23750E)
- Details
- Written by: Newton C. Braga
