This longwave signal booster circuit was found in the 1995 Encyclopedia of Electronic Circuits Volume 5. Note the dimensions of the board. The transistor is a general-purpose transistor.
| Clique na imagem para ampliar |
80-160m Loop Antenna (CB26259E)
