This PLL with operational amplifiers was found in 1969 documentation. The configuration can be adapted to use modern components. The circuit has a gain of 15 V / V and can operate with 10 kHz signals.
| Clique na imagem para ampliar |
PLL (CB6715E)
- Details
- Written by: Newton C. Braga
