Pasternack PE20DV1282 8-Way Power Divider handles up to 30W and operates from a 7GHz to 12.4GHz frequency range in a package interface with SMA female inputs on all the ports. This type-SMA coaxial power splitter features 18dB minimum isolation, 50Ω impedance, and 1.5:1 maximum input VSWR. Pasternack PE20DV1282 8-Way Power Divider also offers 0.6dB maximum amplitude balance, 5° typical and 9° maximum phase balance, and 1.2dB maximum insertion loss. The PE20DV1282 allows the splitting of a single signal into multiple signals with equal magnitude and phase, making it ideal for applications such as test and measurement, SATCOM and military, commercial, and wireless communications.
