onsemi NXH800H120L7QDSG IGBT Module is a 1200V, 800A rated half-bridge IGBT power module. This module is integrated with Field Stop Trench 7 IGBTs and Gen 7 diodes to provide low conduction losses and switching losses. This enables designers to achieve high efficiency and superior reliability. The NXH800H120L7QDSG IGBT module is designed with an isolated base plate and a low inductive layout. This IGBT module is ideally used in motor drives, servo drives, solar drives, and Uninterruptible Power Supply Systems (UPS).
